Wymiary
S / M / L / XL
Waga
13,20kg
Rama
Spark Alloy 6061 custom butted, hydroformed tubes, tapered Headtube,
replaceable derailleur hanger, 135mm, U-Mono Link, rear PM 160, BB height adjustable, 100mm rear travel
Widelec
Rock Shox Recon Silver 29 RL Solo Air, Alloy Steerer, Motion Control Lockout, Rebound adjustable, 100 mm travel
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout activate by one lever
Amortyzator (tył)
DT Swiss M210, Air, ABS Spring, 165 x 38mm, Rebound adjustable, Lockout
Stery
Ritchey OE 1 1/8“, semi integrated 44/50mm
Przerzutka (tył)
Shimano SLX, RD-M663 SGS, Shadow Type, 30 Speed
Przerzutka (przód)
Shimano SLX, FD-M660-10E, DM
Manetki
Shimano Deore, SL-M591-10, Rapidfire Plus, 2 way release, w/gear indicator
Klamki hamulca
Avid Elixir 1
Hamulce
Avid Elixir 1, 180/F and 160/R mm GS Rotor
Korbowód
Shimano FC-M522, 42Ax32Ax24T
Oś korbowodu
Shimano ES25 Octalink, 73-113mm
Kierownica
Scott Pilot T OS 31.8mm, T shape Flat, 680 mm, 9° bend
Mostek
Scott Comp, Oversize 31.8mm, 1 1/8“, -6° angle
Pedały
Wellgo C-128
Sztyca
Scott Comp zero offset, 31.6mm
Siodło
Scott Racing
Piasta (Przód)
Scott Comp Disc IT
Piasta (Tył)
Sram MTH 306 Disc IT
Łańcuch
Shimano CN-HG54
Kaseta
Shimano CS-HG62-10, 11-36 T
Szprychy
DT Swiss Champion Black 1.8mm
Obręcze
Alex XC-49 Disc, 32H, Eyelets
Opony
Schwalbe Rocket Ron, 29 x 2.25, 67EPI Kevlar Bead, Performance Serie
