Wymiary
S / M / L / XL
Waga
12,40kg
Rama
Spark Alloy 6061 custom butted, hydroformed tubes, tapered Headtube, replaceable derailleur hanger, 135mm, U-Mono Link, rear PM 160, BB height adjustable, 100mm rear travel
Widelec
Rock Shox Reba 29 RL Air, Motion Control Lockout, tapered steerer, Rebound adjustable, 100mm travel
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout activate by one lever
Amortyzator (tył)
DT Swiss M210, Air, ABS Spring, 165 x 38mm, Rebound adjustable, Lockout
Stery
Ritchey Comp Plus Tapered 1.5“ - 1 1/8“, semi integrated 50 / 61mm
Przerzutka (tył)
Shimano XT, RD-M780 SGS, Shadow Type, 30 Speed
Przerzutka (przód)
Shimano SLX, FD-M660-10E, DM
Manetki
Shimano SLX SL-M660-10, Rapidfire Plus, 2 way release, w/gear indicator
Klamki hamulca
Avid Elixir 5S
Hamulce
Avid Elixir 5S, 180/F and 160/R mm HS1 Rotor
Korbowód
Shimano XT, FC-M780, Hollowtech 2, 42Ax32Ax24A T
Oś korbowodu
Shimano Cartridge, 73mm shell
Kierownica
Scott Hot Rod Tbar OS 31.8mm, T shape Flat, 680mm, 9° bend
Mostek
Scott Comp, Oversize 31.8mm, 1 1/8“, -6° angle
Pedały
Shimano PD-M505, Clipless pedal
Sztyca
Scott Comp zero offset, 31.6mm
Siodło
Scott Racing
Piasta (Przód)
Scott Comp Disc IT
Piasta (Tył)
Shimano FH-M529 Disc IT
Łańcuch
Shimano CN-HG54
Kaseta
Shimano CS-HG62-10, 11-36 T
Szprychy
DT Swiss Champion Black 1.8mm
Obręcze
Alex XC-49 Disc, 32H, Eyelets
Opony
Schwalbe Rocket Ron, 29 x 2.25, 67EPI Kevlar Bead, Performance Serie
