Wymiary
XXS/47 XS/49 S/52 M/54 L/56
Waga
8.90 kg
Rama
Scott Plasma 2, IMP5 technology, HMF-NET,
Tri Geometry, Plasma 2 seatpost, replaceable hanger
Widelec
Scott Plasma 2, 1 1/8“ carbon, Integrated
Stery
Ritchey Pro Integrated, 45mm drop- in headset
Przerzutka (tył)
Shimano Ultegra RD-6700 G, 20 Speed
Przerzutka (przód)
Shimano Ultegra FD-6700 G
Manetki
Dura-Ace SL-BS 79 Bar End
Klamki hamulca
Profile ABS Alloy
Hamulce
FSA Energy, Lightweight, dual pivot design
Korbowód
FSA Team Issue MegaExo, 53 x 39 T
Oś korbowodu
FSA BB-8681, 68mm
Kierownica
Profile Ozero
Aerobar
Profile T2+ Cobra
Mostek
Profile Dino, 1 1/8", 31.8mm, 80°
Pedały
nil
Sztyca
Plasma 2 with Ritchey WCS adjustable head
Siodło
Fizik Arione Tri 2
Piasta (Przód)
Shimano WH-R501 black
Piasta (Tył)
Shimano WH-R501 black
Łańcuch
Shimano CN-5701
Kaseta
Shimano CS-5700, 10-Speed, 11-25
Szprychy
Shimano WH-R501-30 black
Obręcze
Shimano WH-R501-30 black, 16 Front / 20 Rear
Opony
Continental Ultra Race fold, 700 x 23
