Wymiary
XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
Waga
7.92 kg
Rama
Scott Foil HMF NET, IMP Aero Carbon technology, Road Race geometry, Replaceable Dropout, Standard Seattube, Integrated BB
Widelec
Scott Foil HMF NET, 1 1/8“ - 1 1/4“ Carbon steerer, Integrated Carbon Dropout
Stery
Ritchey Pro Integrated
Przerzutka (tył)
Shimano 105 silver new 2012, RD-5700A, 20 Speed
Przerzutka (przód)
Shimano 105, FD-5700 silver
Manetki
Shimano 105 silver ST-5700, Dual control, 20 Speed
Hamulce
Shimano 105 BR-5700, Super SLR Dual pivot Silver
Korbowód
Shimano 105, Hollowtech II
20-Speed: FC-5700, 53 x 39
Compact: FC-5750, 50 x 34
Oś korbowodu
INT Dura-Ace SM-BB9141
Kierownica
Scott Road Pilot Pro OS, Anatomic 31.8 mm
Mostek
Scott Road Pilot Pro OS, 1 1/8, four Bolt 31.8 mm
Pedały
nil
Sztyca
Ritchey Foil Aero Pro Carbon
Siodło
Scott Road Pro SL
Piasta (Przód)
Shimano WH R501 - 30
Piasta (Tył)
Shimano WH R501 - 30
Łańcuch
Shimano 105 CN-5701
Kaseta
Shimano 105 CS-5700
20-Speed: 11-25 T
Compact: 12-30 T
Szprychy
Shimano WH R501 - 30
Obręcze
Shimano WH R501 - 30, 20 Front / 24 Rear
Opony
Continental Ultra Race fold, 700 x 23
