Wymiary
short / long
Waga
16.80 kg
Rama
VoltageFR Alloy 6061, hydroformed tubing,
Slopestyle&Park geometry, ISCG & ISCG05 tabs,
headtube for 1.5“, IDS interchangeable Dropout,
150-170mm travel
Widelec
RockShox Domain R coil, Coil oil, Reb adjustable,
20mm Maxle, 180mm trave
Amortyzator (tył)
Marzocchi Coil R, Rebound adjustable
Stery
FSA Orbit E 1.5R, alloy cups, 1.5“ Reducer to 1 1/8“, semi-integrated
Przerzutka (tył)
Sram X5, 8 Speed, medium cage
Manetki
Sram X4, Trigger Shifter
Klamki hamulca
Avid Elixir 1
Hamulce
Avid Elixir 1 white, 200/F and 200/R mm Rotor
Korbowód
Truvativ Ruktion 1.0, 165mm, 34T chainring
Oś korbowodu
Truvativ Howitzer XR, 73mm shell
Kierownica
Scott Pilot FR 1.5 Pro, D.B, 38mm rise, 710mm
Mostek
Truvativ Hussefelt OS, 1 1/8“, 0° angle, 40mm ext.
Pedały
Wellgo B155U SCT, Flatpedal w/replaceable pins
Sztyca
Scott DJ zero offset, 31.6mm
Siodło
Scott Voltage FR
Piasta (Przód)
Scott Comp, 20mm thru axle
Piasta (Tył)
Scott DC-22N nutted w/tracknut, 135mm wide
Łańcuch
KMC X8
Kaseta
Sram PG-830, 11-32 T
Szprychy
CN 14 G stainless black
Obręcze
Alex FR 32, 32H, DH disc rim
Opony
Schwalbe Big Betty Freeride Performance,
Front: 26 x2.4, Rrear: 26 x 2.4, Wire Bead, full threat, 50EPI
