Wymiary
short / long
Waga
18.90 kg
Rama
Gambler Alloy 7005, hydroformed tubing,
DH geometry, ISCG & ISCG05 tabs, adjustable
headtube for 1 1/8“ and 1.5“, IDS interchangeable
Dropout with 12mm thru axle, 210mm travel
Widelec
RockShox Boxxer RC, Coil oil, Reb adj. , Maxle
Lite DH 20mm, alloy steerer, 203mm travel
Amortyzator (tył)
Fox VAN RC coil spring preload, Speed sensitive
compression & rebound damping, custom tuned
Reb. & compression adjustable
Stery
FSA Orbit E 1.5R, alloy cups, 1.5“ Reducer to 1 1/8“, semi-integrated
Przerzutka (tył)
Sram X7, 9 Speed, medium cage
Manetki
Sram X5, Trigger Shifter
Klamki hamulca
Avid Elixir 5S Disc
Hamulce
Avid Elixir 5S Disc, 200mm/F and 200/R mm rotor
Korbowód
Truvativ Hussefelt DH 1.1, 36T alloy chainring, white, 165mm
Oś korbowodu
Truvativ HowitzerTM 83mm shell
prowadnica łańcucha
E.thirteen LS-1 ISCG05 Chainguide, w/Taco
Kierownica
Scott Pilot FR 1 Pro, D.B, 20mm rise, 750mm
Mostek
Scott MJ-Boxxer02, 0° angle, 50mm ext.
Pedały
nil
Sztyca
Scott DJ zero offset, 31.6mm
Siodło
Prologo Scratch TRX20 DH Pro STN rails, soft Tail
protection, slip control
Piasta (Przód)
Scott Comp 20mm thru axle
Piasta (Tył)
Scott DHL-150 12mm thru axle, 150mm wide
Łańcuch
Sram PC-951
Kaseta
Sram PG-950, 11-28 T
Szprychy
DT Swiss Industry black 14G 2.0mm
Obręcze
Alex FR 32, 32H, DH disc rim, black
Opony
Schwalbe Downhill, Front: Muddy Mary 26 x2.35
Vertstar, Rear: Wicked Will 26 x 2.35 Trailstar,
Triple Nano Compound, Wire Bead, 2-ply DH
casing, Snake Bite Protection, 67EPI
