Wymiary
S / M / L
Waga
14.20 kg
Rama
Genius LT Alloy 6061, Hydroformed custom
butted, tapered HT, IDS SL 5x135mm Dropout,
BB height adjustable, ISCG05, 185mm rear travel
Widelec
Rock Shox Lyrik RLR, Scott Custom, Air,
Remote Lockout, Tapered steerer, IS Rebound
adjustable, 20mm Maxle, 2 position Air Travel
adjustable 180- 140mm
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout
activate by one lever,
Travel adjust: Lockout - 110 - 185mm
Amortyzator (tył)
Scott Equalizer 3,
3 Modus / Lockout-Traction-Full travel,
sag indicator, dual rebound adjustable
Stery
Syncros AM Comp Tapered 1.5“ - 1 1/8“, semi
integrated 50 / 61mm
Przerzutka (tył)
Shimano XT, RD-M780 SGS, Shadow Type,
30 Speed
Przerzutka (przód)
Shimano SLX, FD-M660-10E, DM
Manetki
Shimano Deore, SL-M591-10, Rapidfire Plus,
2 way release, w/gear indicator
Klamki hamulca
Avid Elixir 3
Hamulce
Avid Elixir 3, 200/F and 180/R mm HS1 Rotor
Korbowód
Shimano FC-M552, 2-piece Design,
42Ax32Ax24T
Oś korbowodu
Shimano Cartridge, shell 73mm&E DM
Kierownica
Scott Pilot 20 Comp 7075 Alloy, 20mm rise,
700mm, OS 31.8mm, Scott lockon gripsScott Pilot 20 Comp 7075 Alloy, 20mm rise,
700mm, OS 31.8mm, Scott lockon grips
Mostek
Scott AM, 4 bolt, 6° angle
Pedały
nil
Sztyca
Scott Comp zero offset, 31.6mm
Siodło
Scott AM
Piasta (Przód)
Scott AM, 20mm thru axle
Piasta (Tył)
Shimano FH-M525 Disc with RWS, 5x135mm
Łańcuch
Shimano CN-HG54
Kaseta
Shimano Deore, CS-HG62-10, 11-36 T
Szprychy
DT Swiss Champion Black 1.8mm
Obręcze
Alex AM-44 Disc, 32H, Eyelets
Opony
Schwalbe Hans Dampf, 26 x 2.35
