Wymiary
S / M / L
Waga
13.90 kg
Rama
Genius LT Carbon Concept, Carbon mainframe
IMP 5, HMF NET, tapered HT, Alloy 6061
D.B. swingarm, IDS SL 12x142mm, BB height
adjustable, ISCG05 Adapter, 185mm rear travel
Widelec
Rock Shox Lyrik RLR, Scott Custom, Air,
Remote Lockout, Tapered steerer, IS Rebound
adjustable, 20mm Maxle, 2 position Air Travel
adjustable 180- 140mm
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout
activate by one lever,
Travel adjust: Lockout - 110 - 185mm
Amortyzator (tył)
Scott Equalizer 3,
3 Modus / Lockout-Traction-Full travel,
sag indicator, dual rebound adjustable
Stery
Syncros AM Pro Tapered 1.5“ - 1 1/8“, semi
integrated 50 / 61mm
Przerzutka (tył)
Sram X9 long cage, 30 Speed
Przerzutka (przód)
Sram X7 DM S3, dual pull
Manetki
Sram X7 Trigger, adjustable clamp, with
Matchmacker Clamp
Klamki hamulca
Avid Elixir 7
Hamulce
Avid Elixir 7, 200/F and 180/R mm HS1 Rotor
Korbowód
Sram X9 3.3, GXP PF, 44Ax33Ax22A T
Oś korbowodu
Sram GXP PF integrated, shell 41x89.5mm
Kierownica
Scott Pilot 20 Pro 7075 Alloy, 20mm rise,
700mm, OS 31.8mm, Scott lockon grips
Mostek
Scott AM, 4 bolt, 6° angle
Pedały
nil
Sztyca
Rock Shox Reverb Stealth, hydraulic remote
system, 31.6mm
Siodło
Scott AM, 7mm CROM rails
Piasta (Przód)
DT Swiss AM 20 Disc IT 20mm
Piasta (Tył)
DT Swiss AM 20 Disc IT with 12mm RWS
12 x 142mm
Łańcuch
Sram PC 1031
Kaseta
Sram PG 1050, 11-36 T
Szprychy
DT Swiss Champion Black
Obręcze
DT Swiss AM 20, 32H, Tubeless ready
Opony
Schwalbe Hans Dampf EVO, 26 x 2.35, 67 EPI,
Kevlar, Snake Skin, Tubeless ready,
Compound Front: Trail Star / Rear: Pace Star
