Wymiary
S / M / L / XL
Waga
11,80kg
Rama
Spark Alloy 6061 custom butted, hydroformed tubes, Tapered Headtube, U-Mono Link, BB height adjustable, replaceable derailleur hanger, 135mm, rear PM 160, 120mm rear travel
Widelec
Rock Shox Reba RL Air, Motion Control Lockout, Tapered steerer, rebound addjustable, 120mm travel
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout activate by one lever,
Amortyzator (tył)
DT Swiss M210, Air, ABS Spring, 190 x 50mm, Rebound adjustable, Lockout
Stery
Ritchey Comp Plus Tapered 1.5“ - 1 1/8“
Przerzutka (tył)
Shimano XT, RD-M780 SGS, Shadow Type, 30 Speed
Przerzutka (przód)
Shimano XT, FD-M660-10E, DM
Manetki
Shimano SLX, SL-M660-10, Rapidfire Plus, 2 way release, w/gear indicator
Klamki hamulca
Avid Elixir 5S
Hamulce
Avid Elixir 5S, 180/F and 160/R mm HS1 Rotor
Korbowód
Shimano XT, FC-M780, Hollowtech 2, 42Ax32Ax24A T
Oś korbowodu
Shimano Cartridge, 73mm shell
Kierownica
Scott Pilot 15 Pro, D.B., 15mm rise, OS, 680mm, Scott lockon grips
Mostek
Scott Comp, Oversize 31.8mm, 1 1/8“, 6° angle
Pedały
Shimano PD-M505, Clipless pedal
Sztyca
Scott Comp, 31.6mm
Siodło
Scott Racing
Piasta (Przód)
Scott Pro Disc IT
Piasta (Tył)
Shimano FH-M525 SL Disc IT
Łańcuch
Shimano CN-HG54
Kaseta
Shimano SLX, CS-HG81-10, 11-36 T
Szprychy
DT Swiss Champion Black 1.8mm
Obręcze
DT Swiss 445d, 32H
Opony
Schwalbe Rocket Ron, 26 x 2.25, 67EPI Kevlar Bead, Performance Serie
