Wymiary
S / M / L / XL
Waga
10,90kg
Rama
Spark Carbon, IMP5 technology, HMF NET, BB 92, Alloy swingarm with 160PM, U-Mono Link, Tapered Headtube, IDS SL dropouts for 142 x 12mm, BB height adjustable, 120mm rear travel
Widelec
Rock Shox SID RLT3 Air, DNA3 custom damper with 3 modes, tapered steerer, rebound adjustable, 120 mm travel
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout activate by one lever, Travel adjust: Lockout - 85 - 120mm
Amortyzator (tył)
Scott DT Nude2, 3 modes Lockout-TC-AT, Ball joints, 190 x 50mm, rebound adjustable
Stery
Ritchey Pro Tapered 1.5" - 1 1/8", semi integrated 50 / 61mm
Przerzutka (tył)
Shimano XT, RD-M780 SGS, Shadow Type, 30 Speed
Przerzutka (przód)
Shimano XT FD-M780-E / DM
Manetki
Shimano XT SL-M780, Rapidfire Plus, 2 way release, Ispec clamp
Klamki hamulca
Shimano XT, BL-M785 Disc
Hamulce
Shimano XT, BR-M785 Disc, 180/F and 160/R mm SM-RT75 Rotor
Korbowód
Shimano XT, FC-M780, Hollowtech 2, 42Ax32Ax24A T
Oś korbowodu
Shimano SM-BB71-41A, shell 41x89.5mm
Kierownica
Scott Pilot 15 Pro, D.B., 15mm rise, OS, 680mm, Scott lockon grips
Mostek
Scott Pro, Oversize 31.8mm, 1 1/8“, 6° angle
Pedały
nil
Sztyca
Scott RC 05-60, 31.6mm
Siodło
Selle Italia SLR XP Team Edition, Vanox
Piasta (Przód)
DT Swiss XR20 Disc IT, RWS QR
Piasta (Tył)
DT Swiss XR20 Disc IT, 12 x 142mm, RWS
Łańcuch
Shimano CN-HG74
Kaseta
Shimano XT, CS-M771-10, 11-36 T
Szprychy
DT Swiss Super Comp black
Obręcze
DT Swiss XR20 Disc, 28H, Tubeless ready
Opony
Schwalbe Rocket Ron EVO, 26 x 2.25, 127EPI Kevlar Bead, Tubeless ready, Pace star compound
