Wymiary
S / M / L / XL
Waga
9,80kg
Rama
Spark Carbon, IMP5 technology, HMX NET, BB 92, Carbon swingarm with 160PM, U-Mono Link, Tapered Headtube, IDS SL dropouts for 142 x 12mm, BB height adjustable, 120mm rear travel
Widelec
Rock Shox SID RLT3 Air, DNA3 custom damper with 3 modes, tapered steerer, rebound adjustable, 120 mm travel
Zdalne sterowanie
Scott Twinloc remote lever, front & rear lockout activate by one lever, Travel adjust: Lockout - 85 - 120mm
Amortyzator (tył)
Scott DT Nude2, 3 modes Lockout-TC-AT, Ball joints, 190 x 50mm, rebound adjustable
Stery
Ritchey Pro Tapered 1.5" - 1 1/8", semi integrated 50 / 61mm
Przerzutka (tył)
Shimano XTR RD-M980 SGS, Shadow Type, 30 Speed
Przerzutka (przód)
Shimano XTR FD-M980-E, DM
Manetki
Shimano XTR SL-M980, Rapidfire Plus, 2 way release, Ispec clamp
Klamki hamulca
Shimano XTR XC M985 Disc
Hamulce
Shimano XTR M985 Disc, 180/F and 160/R mm Ice Tech Rotor
Korbowód
Shimano XTR FC-M980, Hollowtech 2, 42Ax32Ax24A T
Oś korbowodu
Shimano SM-BB91-41A, shell 41x89.5mm
Kierownica
Ritchey Carbon WCS, 18mm Rise, 680 mm, Scott lockon grips
Mostek
Ritchey WCS C-260, oversize 31.8mm, 1 1/8", 6° angle
Pedały
nil
Sztyca
Ritchey WCS Carbon, 31.6mm
Siodło
Selle Italia SLR XP Team Edition, Vanox
Piasta (Przód)
DT Swiss Tricon S10 CL, RWS QR
Piasta (Tył)
DT Swiss Tricon S10 CL, 12 x 142, RWS
Łańcuch
Shimano CN-HG94
Kaseta
Shimano XTR CS-M980, 11-36 T
Szprychy
DT Swiss Aerolite
Obręcze
DT Swiss Tricon S10 CL, 24H, Tubeless
Opony
Schwalbe Rocket Ron EVO, 26 x 2.25, 127EPI Kevlar Bead, Tubeless ready, Pace star compound
